How It Works
The DuroClean™ exhaust system filters air to an ISO 6 standard to create portable clean rooms or isolation rooms for mechanical assembly, additive manufacturing, R&D, and other processes requiring a clean environment. Combined with our DuroRoom retractable enclosure, the DuroClean engineered exhaust system becomes a flexible, cost-effective solution for on-demand clean rooms and isolation rooms wherever and whenever they are needed.
Pair it with:
Key Features
- Negative & Positive Pressure Capability: Isolates hazardous processes or protects a process within a larger manufacturing facility for a safe, controlled environment.
- Neutral Pressure Capability: for simple containment.
- HEPA Filter Configurations: Options include single pass and recirculating designs, with options for cooling and heating and dehumidification.
- Custom Filtration Options: include prefilter, gas phase media, and HEPA and ULPA filters available in 99.97 and 99.99% efficiencies with options for UV light.
- Airflow Options: Laminar or unidirectional airflow systems, as well as turbulent or non-unidirectional airflow systems.
- Air Changes Per Hour (ACH): Combines air changes per hour (ACH) with filtered air circulating into the cleanroom many times per hour (designed to meet ISO classifications).
Technical Specifications
- Fans designed with reverse, incline fan wheels and inlet cones. Non-sparking constructed with fan sizes from 18" to 35" with 5hp to 25hp motors dependent on airflow requirements. Airflow designed at 3.5" static pressure.
- Variable frequency drive (VF) gives complete control of airflow and doubles as a soft starter to eliminate the need for a motor starter.
- Control panel is a lockable fused disconnect and is a C/UL/US listed panel, with an on/off, speed dial control. Prewired. Options include a customized HMI interface. Customer supplies building power.
- Lighting options include C1D1, C1D2, LED lights and troffer lights, depending upon requirements.
- Fire suppression: Wet or dry is available depending upon requirements. Wet for non-retracting only.
For ISO classifications and other technical information, download our DuroClean fact sheet!
DOWNLOAD FACT SHEETDuroClean™ ISO 14644-1 Classifications
All classifications are in accordance with U.S. Federal Standard 209E and represent concentrations of particles using reference size of 0.5 micron.
| Code Compliance | Code Description |
|---|
